[SKXMOD] Cases for Ana-Digi Tuna Modding Kits

Module and along parts presented in the pictures are NOT INCLUDED

CLICK TO SEE PURCHASHING REMINDERS

CLICK TO SEE DIGITAL MANUAL

          DEMONSTRATION

          COMPATIBILITY

• Casio GA-2100/GA-2110 Series
• Casio GMA-S2100 Series
• Casio GA-B2100 Series
• Casio GM-2100 Series
• Casio GBM-2100 Series

GMA-S Variant, if using all original Casio parts. Meaning chapter ring, hour marker, hands and dial. It will have a rim of crevice around the chapter ring. While comparing with other series after completing the build. It is not as full. But does not impact functionality. Only aesthetically.

GA and GMA-S original chapter rings also has an visible cut-out on 1 and 7 o'clock position. As an inevitable flaw from Casio's design, we suggest customers getting our version of upgraded ones. If you have strong concern of such.

Because Casio 2100 models are made differently and in many different series.

We provide different cases for them. And THEY ARE NOT COMPATIBLE WITH EACH OTHER.

The only multi-compatible casing is for both GM-2100 and GBM-2100 series.

Meaning this particular casing can house both GM and GBM models' modules.

Other three casing, for GA-2100/GMA-S2100/GA-B2100, are 1 to 1 compatible only.

Lastly, none of our modding kits are compatible to GM-B2100 series.

Therefore, PLEASE CHECK MODEL FIRST BEFORE PURCHASE!!!

          SPECS:

• Case Material: 316L Stainless Steel (Buttons Pre-installed on cases)
                                      or
• Case Material: Grade 2 Titanium (Buttons Pre-installed on cases)
• Coating: Metal Hardware Fully IP Coated, Rated over 980HV on Vickers Hardness Test
• Case Diameter: 45.6mm (Without Shroud)
• Case Diameter: 51.8mm (With Shroud)
• Lug to Lug: 44.4mm (Without Shroud)
• Top to Bottom 53.2mm (With Shroud)
• Thickness: 16.4mm
• Lug Width: 22mm
• Water Resistant: 500M Machine Tested
• ROV Captured Data, Antarctica Deepsea
• Peak Record: 1510M
• DATA 1, DATA 2

          Product Contains: Case only with buttons installed.

          No bezel, no bezel insert, no shroud, no shroud screws, no crystal.

          Stainless Steel:

• Weight: 150g
• (Case Assembly without Module Installed)
• Weight: 157g
• (Case Assembly with Module Installed)
• Weight: 217g
• (Case & Module and Rubber Band, Retainer, Buckle)
• Weight: 61g
• (Rubber Band, Retainer, Buckle)

          Titanium:

• Weight: 95g
• (Case Assembly without Module Installed)
• Weight: 102g
• (Case Assembly with Module Installed)
• Weight: 153g
• (Case & Module and Rubber Band, Retainer, Buckle)
• Weight: 51g
• (Rubber Band, Retainer, Buckle)

Our case does not always fit all model from above mentioned series.

Because on certain limited/special/collaboration edition model, Casio might do small modification.

Therefore, the general dimension of the inner carbon core is changed. Parts cannot fit into our case anymore.

GAE-2100 series and GM-2100MF-5A is sure won't fit. Please buy with cautions if you have such model.

Because the internal structure for different series are made differently.

We provided different option to choose from. And THEY ARE NOT COMPATIBLE WITH EACH OTHER.

Therefore, CHECK YOUR WATCH MODEL FIRST BEFORE PURCHASING!!!

Attentions:

This listing only contains one item: bare case for SKXMOD Ana-Digi Tuna Modding Kits.

The harden surface only prevents daily minor bumps and scratches from forming.

Does not mean it can withstand impact, puncture, slashes or substantial force in similar form.

The beeping volume will be weaken severely for the full metal enclosure.

Please purchase with discretion if you have concern of regards.

(There might be slight color difference among different accessory and case under same colorway.)

(Due to many variating factor: manufacturing method, material, design and more.)

(Also factor in that we make our own spray painting. Please take into consideration.)

(The term of "Gold" and "Silver" merely represents the colorway.)

(Not meaning coated or made out of true precious metal.)

This product is not manufactured by Apple, Seiko, Casio or related brands.

It is made by SKXMOD.

A third-party product to accessorize aforementioned brands and more.
